Modulation

This function has three parameters amplitude, frequency and phase which may be varied in accordance with data or another modulating signal. For digital modulation which is the main topic in this section. Digital data 1 and 0 is translated into an analog signal (base band signal).Digital modulation is required if digital data has to be transmitted over a medium that only allows for the system -to connect a computer to this system a modem is needed .The modem is needed, the modem then performs the translation of digital data to analog signals and vice versa. There are three basic methods for modulation - amplitude shift keying (ASK), frequency shift keying (FSK); phase shift keying (PSK).These will be discussed in more detail in following sections.



Apart from the translation of digital data into analog signal, wireless transmission requires an additional modulation, an analog modulation that shifts the center frequency of the base band signal generated by the digital modulation up to the radio carrier. For example, the digital modulation translates a 1 Mbps bit stream into a baseband signal cannot be directly transmitted in wireless systems

As for digital modulation, three different basic schemes are known for analog modulation: amplitude modulation, frequency modulation, phase modulation.The reader is referred to Halsall(1996) ,for more details

Modulation can be specified as:

g(t) = At * cos(2*3.142*t+ Pt)

References:
TCP/IP
By
Emmett Dulaney
john white
Sherwood Lawrence
raymondwilliams
Robert Scrimger
kevinwolford
Anthony tilke
